All process is fully automatic, from feeding, welding and cutting;
The production speed cab be adjusted according to the practical need;
The cap size can be changed to 16 to 21 inches (400 – 530mm) according to your need;
Maximum highest capacity can reach 180pcs/min;
High efficiency and long lifespan, low area consumption and low noise;
Raw material can use 9 – 12gsm PP non-woven material, width is 42-46cm2.
Technical parameter
Power supply
220V, 1Ph
Output
3.5KW
Compressor
1-2HP
Productivity
90-180 pcs/min
Ultrasonic system
One machine is equipped with three sets, 2500W, 50K, horn size is 50mm
